Starter Kits MXUxx Starter Kit

Technical data

C-mount kit

article number

• Mono: 11097369 Color: 11097380

name

• MX C-Mount Kit

components

• • C-mount adapter, sealings, screws, retaining bracket, spacers, cover glass and IR filter

cable

article number

• 11140628

name

• cable USB 3.0 die-cast MicB (screw)/A, 3,0 m (KSG U2/KSGU6GV0300G)

features

• • USB 3.0 interface cable with screwable Micro-B connector to USB 3.0 type A connector with screw lock option
  • both connectors with die-cast housing
  • length 3,0 m

heat sink kit

article number

• 11118288

name

• MXU Heat Sink Kit

components

• • Heat sink for MXU board level cameras incl. screws, retaining bracket and thermal conductive pads

process interface cable

article number

• 11098762

name

• cable 8 wires, 0,15 m (Z-ESG JSFV0015)

features

• • cable
  • JST crimp connector
  • female
  • 8-pin
  • open wires at one side
  • AWG32
  • length 0,15 m

interface card

article number

• 11141165

name

• USB3.0 2 Port PCIe Card (ZVA-PCIe_2x_external_USB_3.0)

features

• • 2 port USB 3.0 board
  • chipset: Renesas PD720202
  • tested bandwidth 2950Mbit/s
  • 1 lane PCIe plug board
  • tested driver version: Renesas 3.0.23.0
